Three Phase Electric Steam Generator

China Three Phase Electric Steam Generator supplier

Large Image :  Three Phase Electric Steam Generator

Product Details:

Place of Origin: China
Brand Name: TOLO
Certification: CE
Model Number: TOLO-E45

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: 1 set/carton
Delivery Time: 1-3 workdays
Payment Terms: T/T, Paypal, Western Union,
Supply Ability: 1800 sets
Detailed Product Description



three phase Electric Steam Generator , Roma Steam Bath Generator





Quick Detail:



Main features: TOLO-E steam generator with a host of advanced features.

We produce steam generator over 10years!

  1. Intelligent to heat by segment, fill water with steam, automatic to turn off , a self flushing cycle ,with pressure to drain.
  2. Light can be connected to controller, water inflow to magnetize and filtrate etc.
  3. Intelligent to indicate fault with the code.
  4. To show CH can working for long
  5. Intelligent to save two sets of temperature, can individual set time by memory.





Description:



1. TOLO-E steam generator have middle size to install easily. They have 304 stainless steel water tank, 304 stainless steel heating element with high quality Teflon to prevent water scale.

2. The controller has 6 bottoms to set working stages. working time 1-60mins can be adjusted or long ,the setting temperature of the steam will be in 6-60C degrees and can be adjusted between 35-55C degree (95-131F degree).KSA-E steam generators feature an advanced electronic control with on board diagnostics having a series of LEDs to show each operation of the gernerator. Each generator has 3 groups of heating elements to provide sequential heating (from cold all 3 groups operate for maximum power and rapid heating, when the steam room temperature is almost reached, then group 1 stop, when the required temperature is achieved, then group 2 stop. The group 3 alternates on and off to gently maintain the temperature without large fluctuations improving user comfort).

3. TOLO-E steam generators have an auto drain down with a self flushing cycle to dump the boiler contents in a controlled manner - at the end of each steaming session the drain valve will open and after a short time the cold water inlet valve will open to give a period of continuous flushing and draining. Flushing and draining the boiler reduces the build up of damaging limescale, cooling the elements before the final drainage helps prolong their useful life.
Electronic controls with a digital display to enable temperatures of 30 to 60 degrees centigrade and time duration 1 to 60 minutes or continual operation with additional keys for a steam room light, keyboard lock, manual drain down etc.Safety features include boil dry protection, thermal overload safety cut out and pressure relief valve.

4. Type: Wet Roma Steam bath

  1. control panel: digital and optional
  2. Power output: 4500w
  3. voltage: 110V/220V
  4. Current: 15.6A
  5. Main Material: stainless steel tank and shell
  6. Color: stainless steel
  7. phase: single phase
  8. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  9. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  10. Shape: Cuboid
  11. Size: 405x150x280mm
  12. Room volume(cubic meter): 3~6
  13. Usage: steam sauna room
  14. working time: 1~60 minutes or long time
  15. Heating: heat elements
  16. Power source: Electric
  17. Time Setting: 1-60mins
  18. Temperature range to control: 95 F degree~131 F degree
  19. Temperature range to show on control panel: 43 F degree ~140 F degree





Applications:



For 3~6m³ residential and commercial steam baths

A daily steam bath is a remarkable way to indulge yourself. It causes the perspiration that is the single healthiest thing you can do for your skin. Stress and negativity quickly dissipate in the soft clouds of intense yet comforting heat. A few minutes of steam daily, in the comfort of your own home, is an opportunity to improve your overall well-being in every way.





Specifications:



  1. Control panel with Digital display
  2. Control panel used the advanced inducing technology
  3. Controls sauna temperature 35 degree to 55 degrees
  4. Controls sauna time 1 minute to 60 minutes or long time
  5. Intelligent to heat by segment
  6. Intelligent to fill water with steam
  7. Intelligent to do a self flushing cycle
  8. Light can be connected to controller
  9. Intelligent to indicate fault with the code
  10. Can pause at working
  11. To show CH can working for long
  12. Intelligent to save two sets of temperature, can individual set time by memory
  13. Automatically shuts down when water level is too low
  14. Temperature high limit switch
  15. Waterproof grade: IPX5
  16. Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others
  17. Auto function: auto water inlet , auto drain, auto flushing, auto power off
  18. We will provide some spare parts to our customer as replacement.





Parameters:



Model

Power KW

Room volume (m³)

Power requirements           50/60Hz

Current  (A)

Power        wire (Copper)          N*mm2

Dimensions  CM

Packing dimensions CM

Gross weight kg

TOLO-E30

3.0

2~4

220-240V~

13.6

3*2.5

42.5*16*30

54.5*21.5 *42

10.5~11

TOLO-E40

4.0

3~5

220-240V~

18.2

3*2.5

TOLO-E45

4.5

3.5~5.5

220-240V~

20.5

3*2.5

380-415V3N~

6.8

5*1.5

TOLO-E50

5.0

4~6

220-240V~

22.7

3*2.5

380-415V3N~

9.1

5*1.5

TOLO-E60

6.0

5~7

220-240V~

27.3

3*4.0

380-415V3N~

9.1

5*1.5

TOLO-E70

7.0

5.5~8.5

220-240V~

31.8

3*6.0

47.5*18.5*45

53.5*23 *59

15.6~16.2

380-415V3N~

11.4

5*2.5

TOLO-E80

8.0

7~10

220-240V~

36.4

3*6.0

380-415V3N~

13.6

5*2.5

TOLO-E90

9.0

8~11

380-415V3N~

13.6

5*2.5

16.4~17

TOLO-E105

10.5

9~12

380-415V3N~

15.9

5*2.5

TOLO-E120

12.0

11~14

380-415V3N~

18.2

5*2.5

TOLO-E150

15.0

13~18

380-415V3N~

22.7

5*2.5

51*18.5*46

56.5*23*59

17.5~18.5

TOLO-E180

18.0

16~22

380-415V3N~

27.3

5*4.0

TOLO-E225

22.5

21~28

380-415V3N~

34.1

5*6.0

TOLO-E240

24.0

22~30

380-415V3N~

36.4

5*6.0

Notice: TOLO-E steam generator are equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request.





Competitive Advantage:



Every TOLO-E steam generator is subjected to 6 strictly controlled tests:
    1. 48 hour continual test for circuit board
    2. Controller is tested for all functions
    3. High voltage test
    4. Earthing resistance test
    5. Power test.
    6. Operational test of every steam generator before packing
