Product Details:
Payment & Shipping Terms:
|
| Power Output: | 12.0kw | Time Setting: | 1-60mins |
|---|---|---|---|
| Color: | Grey Green | Current: | 18.2A |
Three Phase Steam Shower Generator 12kw For Hyperthermia Therapy
Quick Detail:
TOLO steam shower generator main feature :
1. Working Time setting :30 minutes to 8 hours
2. Temperature setting: 35-55℃(95-131℉)
3. Protection of water shortage
4. Over-high temperature protection
5. Over-high pressure protection,prevent tank from expanding,in the case steam head has been blocked
6. Light system control
7. Long distance signal transmission,the longest distance can be 50 m
8. The tank material is 304# stainless steel
9. New steam nozzle prevent user from scale
10. The universal wire connection
11. New strong draining system,and auto-back flush,wipe out scale completly ,enlarge the service life extremely
12. The uique dual protection, water inflow once power on,so that prevent heating element from dry burning at beginning
Description:
We have more than 10 years manufacturing experience for sauna equipment.
Parameters:
|
Model |
Power KW |
Room volume (m³) |
Power requirements 50/60Hz |
Current (A) |
Power wire (Copper) N*mm2 |
Dimensions CM |
Packing dimensions CM |
Gross weight kg |
|
KSA-E30 |
3.0 |
2~4 |
220-240V~ |
13.6 |
3*2.5 |
42.5*16*30 |
54.5*21.5*42 |
10.5~ 11 |
|
KSA-E40 |
4.0 |
3~5 |
220-240V~ |
18.2 |
3*2.5 |
|||
|
KSA-E45 |
4.5 |
3.5~5.5 |
220-240V~ |
20.5 |
3*2.5 |
|||
|
380-415V3N~ |
6.8 |
5*1.5 |
||||||
|
KSA-E50 |
5.0 |
4~6 |
220-240V~ |
22.7 |
3*2.5 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
||||||
|
KSA-E60 |
6.0 |
5~7 |
220-240V~ |
27.3 |
3*4.0 |
|||
|
380-415V3N~ |
9.1 |
5*1.5 |
||||||
|
KSA-E70 |
7.0 |
5.5~8.5 |
220-240V~ |
31.8 |
3*6.0 |
47.5*18.5*45 |
53.5*23*59 |
15.6~ 16.2 |
|
380-415V3N~ |
11.4 |
5*2.5 |
||||||
|
KSA-E80 |
8.0 |
7~10 |
220-240V~ |
36.4 |
3*6.0 |
|||
|
380-415V3N~ |
13.6 |
5*2.5 |
||||||
|
KSA-E90 |
9.0 |
8~11 |
380-415V3N~ |
13.6 |
5*2.5 |
16.4~ 17 |
||
|
KSA-E105 |
10.5 |
9~12 |
380-415V3N~ |
15.9 |
5*2.5 |
|||
|
KSA-E120 |
12.0 |
11~14 |
380-415V3N~ |
18.2 |
5*2.5 |
|||
|
KSA-E150 |
15.0 |
13~18 |
380-415V3N~ |
22.7 |
5*2.5 |
51*18.5*46 |
56.5*23*59 |
17.5~ 18.5 |
|
KSA-E180 |
18.0 |
16~22 |
380-415V3N~ |
27.3 |
5*4.0 |
|||
|
KSA-E225 |
22.5 |
21~28 |
380-415V3N~ |
34.1 |
5*6.0 |
|||
|
KSA-E240 |
24.0 |
22~30 |
380-415V3N~ |
36.4 |
5*6.0 |
|||
|
Notice: KSA-E steam generator are equiped with auto drain system. 9~12 KW units could be customized to 220~240V on request. American power input 110V is available according to your requirement. |
||||||||
Steam Shower Generator has:
Applications:
For 11~14 cubic meter residential and commercial steam baths
Competitive Advantage:
Every TOLO steam shower generator is subjected to 6 strictly controlled tests:
1. 48 hour continual test for circuit board
2. Controller is tested for all functions
3. High voltage test
4. Earthing resistance test
5. Power test.
6. Operational test of every steam generator before packing
